- VLT
- 5%
- TSER
- 68%
- IRR
- 90%
- IRER
- 63%
- IR BAND
- 780–2500 nm
- UV REJECTION
- 99%
- VISIBLE REFLECTION EXTERIOR
- 7%
- VISIBLE REFLECTION INTERIOR
- 6%
NANO-CARBON WINDOW FILM
RAYNARY 3
THE STARTING POINTOF PROTECTION.
RAYNARY 3 is VEHICOTEK's nano-carbon automotive window film, designed to bring essential solar control, UV protection and a more comfortable view to everyday driving. By helping manage heat and reduce glare, it creates a more composed cabin experience. Five VLT options let you choose the balance of light, privacy and appearance that suits your vehicle.
PRODUCT / MATERIAL SYSTEM
RAYNARY 3
RAYNARY 3 is the starting point of the RAYNARY platform: a nano-carbon film that brings solar control, UV protection and reduced glare together in a considered everyday window-film system.
Its 1.8 mil construction offers five shades, from 5% to 70% VLT, with 99% UV rejection across the range. Each shade provides a different balance of incoming light and privacy, so selection can be matched to the vehicle, driving preferences and local requirements with a professional installer.
PRODUCT DETAILS
A concise view of the approved public material system, available shade range, primary purpose and warranty pathway.
- MATERIAL SYSTEM
- Nano-Carbon Technology
- AVAILABLE VLT
- 5% / 20% / 35% / 50% / 70%
- PRIMARY FOCUS
- Essential Solar Control & Everyday Comfort
- THICKNESS
- 1.8 mil
- WARRANTY
- Conditional Lifetime Warranty
CORE PERFORMANCE
WHERE PROTECTION BEGINS.
Essential solar control, UV protection and everyday comfort through nano-carbon technology.
- 01
Solar Control
Essential solar control for everyday driving.
- 02
UV Protection
99% UV rejection across the supplied VLT range.
- 03
Reduce Glare
Five shade options support different visible-light transmission preferences.
- 04
Everyday Comfort
Nano-carbon technology supports dependable cabin comfort.
CHOOSE YOUR SHADE
6 VIEWS.
ONE CONSIDERED SYSTEM.
Compare an untinted baseline with every available VLT direction before discussing legal limits and vehicle suitability with an authorized installer.
RAYNARY 333535 VLT
35% visible-light transmission
Screen appearance is an approximate visual comparison, not a scientific optical simulation. Tint laws and permitted VLT levels vary by jurisdiction. Consult an authorized installer for local requirements.
TECHNICAL PERFORMANCE
THE NUMBERS
BEHIND THE FILM.
Published product data presented by model. Use the responsive model cards on smaller screens.* Actual VLT may vary by approximately 3–5% for certain shades. This variation is normal.
| MODEL | VLT | TSER | IRR | IRER | IR BAND | UV REJECTION | VISIBLE REFLECTION EXTERIOR | VISIBLE REFLECTION INTERIOR |
|---|---|---|---|---|---|---|---|---|
| RAYNARY 305 | 5% | 68% | 90% | 63% | 780–2500 nm | 99% | 7% | 6% |
| RAYNARY 320 | 20% | 64% | 90% | 63% | 780–2500 nm | 99% | 7% | 6% |
| RAYNARY 335 | 35% | 58% | 90% | 63% | 780–2500 nm | 99% | 7% | 6% |
| RAYNARY 350 | 50% | 53% | 90% | 63% | 780–2500 nm | 99% | 7% | 6% |
| RAYNARY 370 | 70% | 46% | 90% | 63% | 780–2500 nm | 99% | 7% | 6% |
- VLT
- 20%
- TSER
- 64%
- IRR
- 90%
- IRER
- 63%
- IR BAND
- 780–2500 nm
- UV REJECTION
- 99%
- VISIBLE REFLECTION EXTERIOR
- 7%
- VISIBLE REFLECTION INTERIOR
- 6%
- VLT
- 35%
- TSER
- 58%
- IRR
- 90%
- IRER
- 63%
- IR BAND
- 780–2500 nm
- UV REJECTION
- 99%
- VISIBLE REFLECTION EXTERIOR
- 7%
- VISIBLE REFLECTION INTERIOR
- 6%
- VLT
- 50%
- TSER
- 53%
- IRR
- 90%
- IRER
- 63%
- IR BAND
- 780–2500 nm
- UV REJECTION
- 99%
- VISIBLE REFLECTION EXTERIOR
- 7%
- VISIBLE REFLECTION INTERIOR
- 6%
- VLT
- 70%
- TSER
- 46%
- IRR
- 90%
- IRER
- 63%
- IR BAND
- 780–2500 nm
- UV REJECTION
- 99%
- VISIBLE REFLECTION EXTERIOR
- 7%
- VISIBLE REFLECTION INTERIOR
- 6%
3
ORIGIN
WHERE PROTECTION BEGINS.
The starting point of protection. Essential solar control, UV protection and dependable everyday comfort through nano-carbon technology.
